 Card Dispenser
 |
·
User Selectable Combined Structure
- With Two Cartridge Card
Dispenser KYT-2600 built in
- Magnetic & IC card reader/writer
- RF Card Encoder & Antenna
- Error Card Bin
· Double Capacity with Two Cartridge Card Dispenser-1000
pcs of 0.78mm Thickness Card
· Tow Different Card Issuing is available with One Unit
· ISO All 3 Tracks, Contact and Contactless IC Card
· High Speed Card Issuing : 2~5 Sec/Card
· ISO All 3 Tracks with Single Pass, Contact and Contactless
IC Card
· RS-232C Interface |
|
Model Number |
Remarks |
|
CIM-6100 |
MS,
Read/Write |
|
CIM-6200 |
MS + IC |
|
CIM-6300 |
MS
+ RF |
|
CIM-6400 |
MS + IC + RF |
|
CIM-6500 |
IC,
Read/Write |
|
CIM-6600 |
RF only |
|
CIM-6700 |
IC
+ RF |
|
CIM-6902 |
CIM-6600
Without Antena and M/Board |
Option:
Shutter
HiCo
Side door
300 or 500 Cards Spare Cartridge
|
|
Specification |
|
Card Standard: |
ISO 7811, ISO
7816, Mifare Type A |
|
Card Issuing Time: |
2.3
~ 5 Sec/Card |
|
Coercivity: |
300 Oe, 600 Oe,
1750 Oe~4000 Oe. |
|
Interface: |
RS-232C |
|
Power Supply: |
AC85 ~ 264V Free
Voltage |
|
Operating Temperature: |
0
~ 50c |
|
Humidity: |
20 ~ 90% RH (no
condensing) |
|
CIM 6000 Series
